Focus on customer made high quality power lithium battery and test equiment to very application.
● Born for off road ebike upgrade(Razor,Boom and etc)
● Widely Suitable for 72V ebike upgrade:small size but big power,suit for most of the ebike frame
● EV Grade A grade 10C cylindrical 21700 Cells: support 1000+ cycles @70%DOD and provide a more uniform in-force area and better heat dissipation. 6C continuous charging/discharging current and 575A(1S) peak discharging current.
● Low-Temperature Cut-Off Protection: preventing charging below 0℃ to protect the battery and extend its life, resuming charging at 5℃, and cutting off discharging below -20 0℃;
● Smart Bluetooth: functions of auto-connection, smart control, monitoring battery status, and battery system with Smart App.
● ANT Smart BMS: Monitor the voltage of each single battery in real time;Easyuse UI, overload protection with auto-recovery; .Active balance help maintain your battery automatically and extend your battery life
● 2880 Wh Energy: runs 1-2 hours based on different speed and different motor
● Larger Output Power: Max 41.2KW for peak
● Fast Charging Ways: 10A charger let you finished the charging in 4hours
● Best Service: 24-hour response & 1-year warranty.Free cable leads to controller
BATTERY
Cell Type: |
LS 2170LA |
Warranty: |
1 Years |
Cycle Life: |
1000 cycles at 70% |
Nominal Voltage: |
72V |
Rated Capacity: |
40Ah |
Energy: |
2880Wh |
Max. Expansion (Parallel & Series): |
1P |
Internal Resistance: |
≤20mΩ |
Certifications: |
CE, RoHS, UN38.3 |
Bluetooth: |
√ |
BMS
BMS: |
230A |
Max. Continuous Output Power: |
16.5KW |
Max. Continuous Charge Current: |
10A |
Max. Continuous Discharge Current: |
230A |
Max. Discharge Current 1 Second: |
525A |
CHARGE
Charge Method: |
CC/CV |
Charge Voltage: |
84V ± 0.5V |
Recommend Charge Current: |
5A(0.25C) |
TEMPERATURE
Charge Temperature: |
0℃ to 50℃/32℉ to 122℉ |
Discharge Temperature: |
-20℃ to 60℃ / -4℉ to 140℉ |
Storage Temperature: |
-10℃ to 50℃/14℉ to 122℉ |
Low-Temperature Protection: |
Yes (32℉/0℃) |
Low-Temperature Charging Protection Auto Recovery: |
Yes (41℉/5℃) |
OTHERS
Terminals: |
QS8 Discharge/XT60 Charge (Can customermade) |
Weight Approx.: |
16kgs |
Size: |
225*244*153mm |
Housing Material: |
Rubber like Mat tube |
|
FAQ
BATTERY
Cell Type: |
LS 2170LA |
Warranty: |
1 Years |
Cycle Life: |
1000 cycles at 70% DOD, |
Nominal Voltage: |
72V |
Rated Capacity: |
40Ah |
Energy: |
2880Wh |
Max. Expansion (Parallel & Series): |
1P |
Internal Resistance: |
≤20mΩ |
Certifications: |
CE, RoHS, UN38.3 |
Bluetooth: |
√ |
BMS
BMS: |
230A |
Max. Continuous Output Power: |
16.5KW |
Max. Continuous Charge Current: |
10A |
Max. Continuous Discharge Current: |
230A |
Max. Discharge Current 1 Second: |
525A |
CHARGE
Charge Method: |
CC/CV |
Charge Voltage: |
84V ± 0.5V |
Recommend Charge Current: |
5A(0.25C) |
TEMPERATURE
Charge Temperature: |
0℃ to 50℃/32℉ to 122℉ |
Discharge Temperature: |
-20℃ to 60℃ / -4℉ to 140℉ |
Storage Temperature: |
-10℃ to 50℃/14℉ to 122℉ |
Low-Temperature Protection: |
Yes (32℉/0℃) |
Low-Temperature Charging Protection Auto Recovery: |
Yes (41℉/5℃) |
OTHERS
Terminals: |
QS8 Discharge/XT60 Charge (Can customermade) |
Weight Approx.: |
8kgs |
Size: |
225*244*153mm |
Housing Material: |
Rubber like mat tube |
