Lead Acid Battery Capacity Tester 1 by PSN Energy
Company Advantages
· PSN Energy Lead Acid Battery Capacity Tester is constructed from well-chosen raw materials.
· The complete quality control system makes sure that this product is of high quality.
· Shenzhen PSN Energy Co.,Ltd is a customer-centric company.
| Model | PSN37-0516040 |
| Number Of Device Channels | 160 channels |
| Overall Dimension | Width 1880mm× Depth 1008mm× Height 2033mm |
| Color | White |
| Jig Form | Electric clamp opening, enhanced flat head clamp |
| Fixture Spacing | 81mm |
| Support Battery Specifications | 1. Battery compatible length 90-210mm，2. Thickness 16-70mm，3. Height 80-230mm，4. Battery tabs 40-150mm |
| Working Power Supply | Three-phase 5 wire system AC380V±10%,50HZ |
| Power Factor | 0.99 @220V AC, Fully loaded, power grid THDu≤2% |
| Ac Current Distortion Rate | <5% @220V AC, Fully loaded, power grid THDu≤2% |
| Power Consumption | ≤28 KW |
| Charging Efficiency Of Whole Machine | Charge≥80%; discharge≥70% |
| Work Environment | Indoors, temperature is 10-30℃ under air convection. |
| Heat-Dissipating Method | Air cooling |
|
Voltage Testing Range |
DC 0~5V |
|
Battery Voltage Range |
Charge DC 0～4.5V；Discharge DC 4.5～2V |
|
Constant Voltage Range |
DC 2~4.5V |
|
Voltage Accuracy |
±(0.5% Reading+0.5% Full Degree) |
|
Voltage Resolution |
0.1mV |
|
Voltage Stability |
≤(±1mV) |
|
Current Range |
Charge DC100mA～ 40A；Discharge DC 100mA～40A |
|
Accuracy Of Current |
±(0.5% Reading+0.5% Full Degre) |
|
Current Steady Reading |
≤(±1mA) |
|
Control Mode |
Computer Control Equipment Work，whole cabinet control/single board startup/single point startup, with scanning system |
|
Communication Mode |
485 serial port communication (baud rate 57600)/TCP communication/chart |
|
Workflow Setting |
Up to 32 work steps and 256 cycles can be set, with the function of nested loops |
|
Charging Mode |
The function of nested loops |
|
Charge Cutoff Condition |
Constant, current, constant, voltage, -△V |
|
Discharge Mode |
Voltage, current, time, capacity |
|
Discharge Cutoff Condition |
Voltage, time, capacity |
|
Time Range |
0~ 30000 minutes/work step, time unit: min |
|
Time Accuracy |
≤±1%0 |
|
Sampling Tour Period |
1s-60s optional |
Product Advantage
Product Display
FAQ
Company Features
· With abundant know-how in manufacturing Lead Acid Battery Capacity Tester, Shenzhen PSN Energy Co.,Ltd stands out among thousands of manufacturers in China market.
· To manufacture these Lead Acid Battery Capacity Tester, our deft professionals use quality-approved raw materials and ultramodern techniques.
· Our goal is to have no accidents and to mitigate impacts on the environment by working with our stakeholders, peers, and others to promote responsible environmental practices and continuous improvement.
Product Details
The details of Lead Acid Battery Capacity Tester are presented to you in the following section.
Application of the Product
Our Lead Acid Battery Capacity Tester meets the needs of multiple industries and fields.
We are willing to understand the real needs of our customers. Then, we will provide the best solutions to their needs.
Product Comparison
PSN Energy's Lead Acid Battery Capacity Tester has been substantially improved in a scientific way, as shown in the following aspects.
