BATTERY
Cell Type: |
LiFePO4 Prismatic 3.2V 105Ah |
Warranty: |
5 Years |
Cycle Life: |
4000+Times |
Nominal Voltage: |
51.2V |
Rated Capacity: |
105Ah |
Energy: |
5376Wh |
Certificate: |
CE, UL, ISO 9001, ROHS, FCC, MSDS certificati |
Charger: |
Built-in waterproof charger (optional) |
BMS
BMS: |
105A |
Max. Continuous Discharge Current: |
105A |
Max. Discharge Current 10 Second:: |
200A |
CHARGE
Charge Method: |
CC/CV |
Charge Voltage: |
57.6V ± 0.8V |
Recommend Charge Current: |
20A(0.2C) |
TEMPERATURE
Charge Temperature: |
0℃ to 50℃/32℉ to 122℉ |
Discharge Temperature: |
-20℃ to 60℃ / -4℉ to 140℉ |
Storage Temperature: |
-10℃ to 50℃/14℉ to 122℉ |
Low-Temperature Protection: |
Yes (32℉/0℃) |
Low-Temperature Charging Protection Auto Recovery: |
Yes (41℉/5℃) |
OTHERS
Terminals: |
Can be customization |
Weight Approx.: |
45kgs |
Size: |
509*333*245mm |
Housing Material: |
metal case |
Protection Class: |
IP54 |
FAQ
Company Advantages
· When producing PSN Energy 48v 30ah Lithium Ion Battery Pack, our personnel makes use of advanced production techniques.
· Compared with other products, the product has obvious superiority such as long service life, stable performance, and good usability.
· Shenzhen PSN Energy Co.,Ltd introduced advanced production equipment and other facilities to make sure high quality of 48v 30ah Lithium Ion Battery Pack.
Company Features
· Shenzhen PSN Energy Co.,Ltd is one of the most influential 48v 30ah Lithium Ion Battery Pack professional R & D, manufacturing companies.
· Our company attracts and retains top talents. As skilled problem-solvers for us and our customers, these people have all the skills, knowledge and competency of specialist trades to develop extraordinary products.
· Our goal is to head ahead of the market competitors. Currently, we will invest more in introducing advanced and high-tech manufacturing facilities which can help improve product quality.
Application of the Product
Our 48v 30ah Lithium Ion Battery Pack meets the needs of multiple industries and fields.
While providing quality products, PSN Energy is dedicated to providing personalized solutions for customers according to their needs and actual situations.
BATTERY
Cell Type: |
LiFePO4 Prismatic 3.2V 105Ah |
Warranty: |
5 Years |
Cycle Life: |
4000 +Times |
Nominal Voltage: |
51.2V |
Rated Capacity: |
105Ah |
Energy: |
5376Wh |
Certifications: |
CE, UL, ISO 9001, ROHS, FCC, MSDS certificati |
Charger: |
Built-in waterproof charger (optional) |
Bluetooth: |
√ |
BMS
BMS: |
105A |
Max. Continuous Discharge Current: |
105A |
Max. Discharge Current 10 Second: |
200A |
CHARGE
Charge Method: |
CC/CV |
Charge Voltage: |
57.6V ± 0.8V |
Recommend Charge Current: |
20A(0.2C) |
TEMPERATURE
Charge Temperature: |
0℃ to 50℃/32℉ to 122℉ |
Discharge Temperature: |
-20℃ to 60℃ / -4℉ to 140℉ |
Storage Temperature: |
-10℃ to 50℃/14℉ to 122℉ |
Low-Temperature Protection: |
Yes (32℉/0℃) |
Low-Temperature Charging Protection Auto Recovery: |
Yes (41℉/5℃) |
OTHERS
Terminals: |
509*333*245mm |
Weight Approx.: |
45kgs |
Size: |
509*333*245mm |
Housing Material: |
metal case |
Protection Class: |
IP54 |
