Lithium Ion Battery Tester - - PSN Energy-4
Product details of the lithium ion battery tester
Quick Overview
PSN Energy lithium ion battery tester is designed and manufactured by using the advanced technology. Our focus on researching and developing new technology makes the quality and performance of the product lead in the industry. The offered product is extensively used for customers in the industry.
Product Description
PSN Energy's lithium ion battery tester has more advantages over similar products in terms of technology and quality.
Specification
| Battery | |
| Battery type | LiFePO4 |
| Capacity | 25.6V40Ah/1024WH |
| BMS type | 8S |
| BMS Discharge / Charge Current | 50A |
| AC Output | |
| Continue power | 1000W |
| Peak power | 2000W |
| Wave type | Pure Sin Wave |
| AC output voltage | 220V |
| Frequency | 50Hz(60Hz optional） |
| UPS conversion time | S10ms |
| AC outlet | *4 |
| DC Out and Light | |
| DC5521 12V output | *2 (total 12V 5A) |
| Cigarette output | 12V 6A |
| USB Type-A | *2(2A) |
| USB Type-C | *1 PD18W |
| LCD display | have |
| Switches button | 4 |
| LED Light | 12V5W max |
| Solar MPPT Controller | |
| MPPT Conversion Type | Buck |
| PV Voltage range | 36-50V |
| PV array max power | 700W |
| MPPT charge voltage(CV) | 29.2V |
| MPPT charge curent(max) | 20A |
| MPPT PV input Socket | XT60 Male |
| Ac Charge | |
| AC to DC charger | 29.2V 10A (or customized) |
| AC/DC Charge socket | XT60 Female |
| Maximum charge current | 20A(or customized) |
| General | |
| Working Temperature(° C) | -10-55 |
| Storage Temperature(° C) | -10-50 |
| Weight(Kg) | customized |
| Size(mm) | 213*232*360mm |
