Focus on customer made high quality power lithium battery and test equiment to very application.
Company Advantages
· PSN Energy Electric Vehicle Battery Pack is manufactured only with high-quality materials and to achieve it, we have established a strict material selection specification.
· By cause of the design of Electric Vehicle Battery Pack,PSN Energy enjoys a good reputation.
· PSN Energy attaches great importance to producing Electric Vehicle Battery Pack with high quality.
BATTERY
Cell Type: |
LiFePO4 Prismatic 3.2V 105Ah |
Warranty: |
5 Years |
Cycle Life: |
4000+Times |
Nominal Voltage: |
51.2V |
Rated Capacity: |
105Ah |
Energy: |
5376Wh |
Certificate: |
CE, UL, ISO 9001, ROHS, FCC, MSDS certificati |
Charger: |
Built-in waterproof charger (optional) |
BMS
BMS: |
105A |
Max. Continuous Discharge Current: |
105A |
Max. Discharge Current 10 Second:: |
200A |
CHARGE
Charge Method: |
CC/CV |
Charge Voltage: |
57.6V ± 0.8V |
Recommend Charge Current: |
20A(0.2C) |
TEMPERATURE
Charge Temperature: |
0℃ to 50℃/32℉ to 122℉ |
Discharge Temperature: |
-20℃ to 60℃ / -4℉ to 140℉ |
Storage Temperature: |
-10℃ to 50℃/14℉ to 122℉ |
Low-Temperature Protection: |
Yes (32℉/0℃) |
Low-Temperature Charging Protection Auto Recovery: |
Yes (41℉/5℃) |
OTHERS
Terminals: |
Can be customization |
Weight Approx.: |
45kgs |
Size: |
509*333*245mm |
Housing Material: |
metal case |
Protection Class: |
IP54 |
FAQ
Company Features
· Shenzhen PSN Energy Co.,Ltd is a foreign trade enterprise focusing on the developing and manufacturing of Electric Vehicle Battery Pack. We are an international manufacturer and supplier.
· By overcoming technical difficulties, PSN Energy has greatly improved its production efficiency. In order to meet the needs of more customers, PSN Energy has always focused on technological innovation.
· To provide the highest quality Electric Vehicle Battery Pack is our persistent mission to satisfy the customers and achieve the value of ourselves. Ask!
Product Comparison
After improvement, the Electric Vehicle Battery Pack produced by PSN Energy is more brilliant in the following aspects.
Enterprise Advantages
PSN Energy thinks highly of talents cultivation. At present, we have a group of employees who effective guarantees the long-term development of our company. They are excellent, professional, dedicated and strict.
Our company takes customer's satisfaction as an important criterion and provides thoughtful and reasonable services for customers in a professional and dedicated attitude.
In the future, PSN Energy will always adhere to integrity-based and customer-oriented business. Besides, we will carry forward our enterprise spirit to be loyal, dedicated, and pragmatic. We are committed to becoming a modern and competitive enterprise in the industry.
Established in PSN Energy has gone through a major change in the past years.
Our company sells products to many central cities in China, and is stationed in many large supermarkets and stores. We also export our products to North America, Europe, Australia and Southeast Asia.
BATTERY
Cell Type: |
LiFePO4 Prismatic 3.2V 105Ah |
Warranty: |
5 Years |
Cycle Life: |
4000 +Times |
Nominal Voltage: |
51.2V |
Rated Capacity: |
105Ah |
Energy: |
5376Wh |
Certifications: |
CE, UL, ISO 9001, ROHS, FCC, MSDS certificati |
Charger: |
Built-in waterproof charger (optional) |
Bluetooth: |
√ |
BMS
BMS: |
105A |
Max. Continuous Discharge Current: |
105A |
Max. Discharge Current 10 Second: |
200A |
CHARGE
Charge Method: |
CC/CV |
Charge Voltage: |
57.6V ± 0.8V |
Recommend Charge Current: |
20A(0.2C) |
TEMPERATURE
Charge Temperature: |
0℃ to 50℃/32℉ to 122℉ |
Discharge Temperature: |
-20℃ to 60℃ / -4℉ to 140℉ |
Storage Temperature: |
-10℃ to 50℃/14℉ to 122℉ |
Low-Temperature Protection: |
Yes (32℉/0℃) |
Low-Temperature Charging Protection Auto Recovery: |
Yes (41℉/5℃) |
OTHERS
Terminals: |
509*333*245mm |
Weight Approx.: |
45kgs |
Size: |
509*333*245mm |
Housing Material: |
metal case |
Protection Class: |
IP54 |
FAQ
