Focus on customer made high quality power lithium battery and test equiment to very application.
Custom Lithium Batteries by PSN Energy
BATTERY
|
Cell Type: |
LiFePO4 Prismatic 3.2V 105Ah |
|
Warranty: |
5 Years |
|
Cycle Life: |
4000+Times |
|
Nominal Voltage: |
73.6V |
|
Rated Capacity: |
105Ah |
|
Energy: |
7728Wh |
|
Certificate: |
CE, UL, ISO 9001, ROHS, FCC, MSDS certificati |
|
Charger: |
Built-in waterproof charger (optional) |
BMS
|
BMS： |
105A |
|
Max. Continuous Discharge Current： |
105A |
|
Max. Discharge Current 10 Second：： |
200A |
CHARGE
|
Charge Method: |
CC/CV |
|
Charge Voltage: |
82.8V ± 0.8V |
|
Recommend Charge Current: |
3A(0.2C) |
TEMPERATURE
|
Charge Temperature: |
0℃ to 50℃/32℉ to 122℉ |
|
Discharge Temperature: |
-20℃ to 60℃ / -4℉ to 140℉ |
|
Storage Temperature: |
-10℃ to 50℃/14℉ to 122℉ |
|
Low-Temperature Protection: |
Yes (32℉/0℃) |
|
Low-Temperature Charging Protection Auto Recovery: |
Yes (41℉/5℃) |
OTHERS
|
Terminals: |
Can be customization |
|
Weight Approx.: |
70kgs |
|
Size: |
558*334*300mm |
|
Housing Material: |
metal case |
|
Protection Class: |
IP54 |
FAQ
Company Advantages
· custom lithium batteries, designed by our professional design experts, are very popular in the industry.
· Each product is rigorously tested before delivery.
· Shenzhen PSN Energy Co.,Ltd has done a solid job in its sales network.
Company Features
· PSN Energy brand mainly focuses on producing custom lithium batteries.
· Our professional R&D team has accumulated abundant technical know-how. This advantage enables them to create satisfactory products including custom lithium batteries that will meet market requirements and provide professional advice.
· Consistently developing first-class custom lithium batteries with our wisdom and power is our guiding policy. Call!
Application of the Product
PSN Energy's custom lithium batteries is widely applicable in the industry.
PSN Energy insists on providing customers with Lithium battery pack,lithium battery tester,lithium battery swapping station of high quality and a one-stop solution that's comprehensive and efficient.
BATTERY
|
Cell Type: |
LiFePO4 Prismatic 3.2V 105Ah |
|
Warranty: |
5 Years |
|
Cycle Life: |
4000 +Times |
|
Nominal Voltage: |
73.6V |
|
Rated Capacity: |
105Ah |
|
Energy: |
7728Wh |
|
Certifications: |
CE, UL, ISO 9001, ROHS, FCC, MSDS certificati |
|
Charger: |
Built-in waterproof charger (optional) |
|
Bluetooth: |
√ |
BMS
|
BMS： |
105A |
|
Max. Continuous Discharge Current： |
105A |
|
Max. Discharge Current 10 Second： |
200A |
CHARGE
|
Charge Method: |
CC/CV |
|
Charge Voltage: |
82.8V ± 0.8V |
|
Recommend Charge Current: |
20A(0.2C) |
TEMPERATURE
|
Charge Temperature: |
0℃ to 50℃/32℉ to 122℉ |
|
Discharge Temperature: |
-20℃ to 60℃ / -4℉ to 140℉ |
|
Storage Temperature: |
-10℃ to 50℃/14℉ to 122℉ |
|
Low-Temperature Protection: |
Yes (32℉/0℃) |
|
Low-Temperature Charging Protection Auto Recovery: |
Yes (41℉/5℃) |
OTHERS
|
Terminals: |
509*333*245mm |
|
Weight Approx.: |
70kgs |
|
Size: |
558*334*300mm |
|
Housing Material: |
metal case |
|
Protection Class: |
IP54 |
FAQ
Our Bluetooth batteries are delivered in the off state, the virtual voltage of the battery terminal is 3V-5V, this is a normal phenomenon, just use the AC-DC lithium battery charger to charge the battery and turn on the battery, it can be used normally.
If you intend to store the battery for an extended period without use, we recommend charging it to a SOC of 30% to 50% and conducting maintenance every three months. These measures will help preserve its functionality and performance in the long run.
Recommend charging voltage: 76.55V ~ 78.7V
Recommend charging current: 20A (0.2C): the battery will be fully charged in around 5hrs to 100% capacity. 50A (0.5C): the battery will be fully charged in around 2hrs to around 97% capacity.
Attention:
Connect the charger to the battery before connecting it to the grid power in case of sparks.
Remember to disconnect the charger from the battery after fully charging.
● Faster Acceleration: A 72V system provides higher low-end torque, allowing for quicker acceleration.
● Increased Power: With more overall power, a 72V setup is beneficial for tackling hills and challenging terrain.
● Improved Efficiency: 72V batteries draw fewer amps, making them more efficient than 36V batteries. This efficiency translates to longer usage on a single charge.
● Better for Rough Terrain: A 72V system handles rougher terrain effectively, enabling off-road capabilities and easier navigation of hilly areas.
